Although we have no any printing machine, we should know the specification of many machines and tools used in our book production. We should know exactly about the things that are required in the production of the book. There are various sizes of many components of preprinting, printing machines, cutting machines and binding machine. This different sizes will greatly affect in determining the book dimensions, paper type, ink type and color as well as in the making master, the designing of contents and cover.
Here are some list the size of various components of the printing machine relating to book production process. Here in part 1 we shall find 3 lists of : A, offset machine and its plate size, B. ink print type, C. dampening roll dimension.
A. List of Offset Machine and Plate Size
Multilith 254 x 381 x 0,15
Toko 254 x 394 x 0,15
Ryoby 405 x 483 x 0,15
GTO 46 457 x 381 x 0,15
Hamada 467 x 400 x 0,15
GTO 52 510 x 400 x 0,15
Thomson 553 x 420 x 0,15
Mercedes 570 x 506 x 0,20
Solna 125 645 x 510 x 0,20
Kord 650 x 550 x 0,30
Kors/Sorm 724 x 615 x 0,30
Roland Fob 730 x 610 x 0,30
Sord 915 x 715 x 0,30
Parva IIC 925 x 740 x 0,30
Sors 1030 x 820 x 0,30
Sors 1030 x 820 x 0,30
Oliver 58 570 x 510 x 0,30
B. List of Ink Print
TC – 001 Medium
TC – 010 Transparant Yellow
TC – 015 Medium Yellow
TC – 020 Medium Yellow
TC – 025 Deep Yellow
TC – 045 Deep Yellow
TC – 075 Orange
TC – 095 Orange
TC – 105 Orange
TC – 115 Bronze Red
TC – 135 Red
TC – 155 Red
TC – 165 Rubine Red
TC – 170 Deep red
TC – 175 Deep Red
TC – 180 Rose
TC – 190 Rose
TC – 195 Magenta
TC – 210 Magenta
TC – 220 Purple
TC – 240 Violet
TC – 266 Violet
TC – 280 Bronze Blue
TC – 305 Reflex Blue
TC – 336 Milori Blue
TC – 345 Light Blue
TC – 355 Cyan
TC – 360 Cyan
TC – 370 Peacock Blue
TC – 385 Bluish White
TC – 405 Green
TC – 416 Green
TC – 436 Green
TC – 455 Yellow Green
TC – 495 Yellow Green
TC – 108 Brown
TC – 513 Lemon Yellow
TC – 520 Black
TC – 529 Black
TC – 530 Black
TC – 540 Black
TC – High Gloss Black No. 3
TC – 627 Gold Ink
TC – 628 Gold Ink
TC – 629 Gold Ink
TC – 700 White
TC – 00 Varnish
TC – Petro Drier
TC – N Contex
TC – Overprinting Varnish
TC – High Gloss OPV
TC – Silver Ink
TC – WS Black
TC – Gold Varnish
TC - 107 Black
TC - Royal Black
C. List of Dampening Roll
1. Multilith 350 x 25 x 20 mm
2. Gestetner 350 x 35 x 25 mm
350 x 45 x 35 mm
3. Multilith 350 x 50 x 40 mm
4. Gestetner 350 x 60 x 45 mm
5.Double Quarto 550 x 25 x 20 mm
6.Hamada 700 CD 550 x 35 x 25 mm
7. Ryoby 480 550 x 35 x 25 mm
8. Rotaprint 550 x 45 x 35 mm
9. Double Quarto 550 x 60 x 45 mm
10. Thomson Crown 600 x 35 x 25 mm
11. Hamada 800 DX 600 x 35 x 25 mm
12. Romayor 600 x 45 x 35 mm
13. Thomson Crown 600 x 50 x 40 mm
14. Adas Dominant 700 x 35 x 25 mm
15. Mercedes/KorD 64 700 x 50 x 40 mm
16. Mercedes/Solna 700 x 60 x 45 mm
17. KorS/Oliver 8 800 x 50 x 40 mm
18. SorM/Oliver 12 800 x 70 x 55 mm
19. Sor/Komori/Sprint 900 x 70 x 55 mm
20. Sord 1050 x 60 x 55 mm
21. SorD/Parva IIC 1050 x 70 x 55 mm
22. Crabtree 1050 x 80 x 65 mm
23. Mesin RRC 1050 x 60 x 45 mm
24. Komori Lithrone 1100 x 70 x 55 mm
25. Komori Perfector 1200 x 60 x 45 mm
26. SorS 1200 x 70 x 55 mm
27. Rekord IIIB 1200 x 80 x 65 mm
28. Hamada AOR 36 1200 x 60 x 45 mm
29. Hamada NOR 32 1200 x 105 x 85mm
30. Komori Kosmo 1500 x 80 x 65mm
31. Roland Ultra 5 1500 x 90 x 70mm
